FREE CHLORINE (TRO) is measured using amperometry without the use of membranes, electrolytes or reagents and consequently requires far less maintenance than conventional systems. It’s integrated pH and temperature sensors enable onboard compensation for temperature and pH. It measures Free Chlorine using auto-ranging from 0 to 15 ppm. Unlike ORP, the relationship of chlorine to signal is linear, not logarithmic, resulting in higher accuracy.
$0.00
Out of stock
FREE CHLORINE (TRO) is measured using amperometry without the use of membranes, electrolytes or reagents and consequently requires far less maintenance than conventional systems. It’s integrated pH and temperature sensors enable onboard compensation for temperature and pH. It measures Free Chlorine using auto-ranging from 0 to 15 ppm. Unlike ORP, the relationship of chlorine to signal is linear, not logarithmic, resulting in higher accuracy.
You must be logged in to post a review.
| Parameter: | Value: | Resolution: | Notes: |
|---|---|---|---|
| Free Chlorine, Bromine or TRO | 0 to 15 PPM | 0.01 | Auto Ranging |
| Oxidation Reduction Potential (ORP) | -1100 to 1100 mV | 1 | Rapid Response |
| Conductivity | 0 to 40,000 μS | 10 | Auto Ranging |
| pH | 2 to 12 | 0.01 | Differential, Long-Life |
| Temperature | 0 to 100° C | 0.1 | Lower maintenance, no down time |
| Pressure | 150 PSI (10 Bar) | ||
| Ambient Temperature Range (operating) | -20 to 140° F (-4 to 60° C) | Modules with display will suff er some performance degradation at lower temperatures | |
| Sample Conductivity | >50 μS/cm at 25°C | ||
| Process Connection | 2” NPT | ||
| Shipping Weight | 4 lb. (1.8 kg) | ||
| Measurement Frequency | 30 to 60 Sec | Seawater (30 to 60 seconds) | |
| Cable Length | 10 Feet (3 M) | Longer cables are available by special order |
Measures
Lower Maintenance
Easier Installation
Display / Transmitter
